Page 10
DS30651 Rev. 7 - 2
10 of 10
LMN200B01
www.diodes.com
A
M
J
L
D
F
B C
H
K
IMPORTANT NOTICE
Diodes, Inc. and its subsidiaries reserve the right to make changes without further notice to any product herein to make corrections, modifications, enhance-
ments, improvements, or other changes. Diodes, Inc. does not assume any liability arising out of the application or use of any product described herein;
neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall assume all risks of such
use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website, harmless against all damages.
LIFE SUPPORT
The products located on our website at
www.diodes.com are not recommended for use in life support systems where a failure or malfunction of the
component may directly threaten life or cause injury without the expressed written approval of Diodes Incorporated.
SOT-26
Dim
Min
Max
Typ
A
0.35
0.5
0.38
B
1.5
1.7
1.6
C
2.7
3
2.8
D
-
-
0.95
F
-
-
0.55
H
2.9
3.1
3
J
0.013
0.1
0.05
K
1
1.3
1.1
L
0.35
0.55
0.4
M
0.1
0.2
0.15
α
0
°
8°
-
All Dimensions in mm
Mechanical Details
Fig. 22
Suggested Pad Layout: (Based on IPC-SM-782)
X
Z
Y
C
E
E
G
Figure 23
Dimensions
SOT-26*
Z
3.2
G
1.6
X
0.55
Y
0.8
C
2.4
E
0.95
Fig. 23
T
C
U
D
O
R
P
W
E
N
