MBR20100C
Document number: DS36950 Rev. 2 - 2
5 of 13
April 2014
© Diodes Incorporated
MBR20100C
Maximum Ratings
(Each Diode Leg) (Note 7)
Characteristic
Symbol
Rating
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
100
V
Average Rectified Forward Current
(Rated V
R
) T
C
= +122
C
I
F(AV)
10
A
Peak Repetitive Forward Current
(Rated V
R
, Square Wave, 20kHz) T
C
= +118
C
I
FRM
20
A
Non Repetitive Peak Surge Current
(Surge Applied at Rated Load Conditions Half Wave,
Single Phase, 60Hz)
I
FSM
150
A
Non Repetitive Peak Reverse Current, t
P
= 3µs
I
RSM
2
A
Operating Junction Temperature Range (Note 8)
T
J
+150
o
C
Storage Temperature Range
T
STG
-65 to +150
o
C
Voltage Rate of Change (Rated V
R
)
dv/dt
10000
V/µs
ESD (Machine Model = C)
–
>400
V
ESD (Human Body Model = 3B)
–
>8000
V
Notes: 7.
Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
8. The heat generated must be less than the thermal conductivity from Junction to Ambient: dP
D
/dT
J
< 1/
θ
JA
.
Thermal Characteristics
Characteristic
Symbol
Rating
Unit
Maximum Thermal Resistance (Junction to Case)
(Note 9)
R
θJC
TO-220-3 (2)
2.5
o
C/W
TO-220F-3 (Option 1)
4.5
TO-252-2 (1)
2.0
TO-263-2
2.0
Maximum Thermal Resistance (Junction to Ambient)
(Note 9)
R
θJA
TO-220-3 (2)
60
o
C/W
TO-220F-3 (Option 1)
60
TO-252-2 (1)
50
TO-263-2
50
Note 9: Device mounted on heat sink, with minimum recommended pad layout per
