74LVC1G10
SINGLE 3 INPUT POSITIVE NAND GATE
74LVC1G10
Document number: DS35121 Rev. 3 - 2
9 of 13
www.diodes.com
October 2011
© Diodes Incorporated
NEW PROD
UC
T
Ordering Information
Device
Package
Code
Packaging
(Note 7)
7” Tape and Reel
Quantity Part Number Suffix
74LVC1G10W6-7 W6 SOT26 3000/Tape & Reel -7
74LVC1G10DW-7 DW SOT363 3000/Tape & Reel -7
74LVC1G10FW4-7 FW4 DFN1010 5000/Tape & Reel -7
74LVC1G10FZ4-7 FZ4 DFN1410 5000/Tape & Reel -7
Notes: 5. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
http://www.diodes.com/datasheets/ap02001.pdf.
6. The taping orientation is located on our website at http://www.diodes.com/datasheets/ap02007.pdf
