74LVC1G10
SINGLE 3 INPUT POSITIVE NAND GATE
74LVC1G10
Document number: DS35121 Rev. 3 - 2
8 of 13
www.diodes.com
October 2011
© Diodes Incorporated
NEW PROD
UC
T
Parameter Measurement Information (cont.)
V
CC
Inputs
V
M
C
L
R
L
V
I
t
r
/t
f
1.8V±0.15V V
CC
≤2ns V
CC
/2 30pF 1K Ω
2.5V±0.2V V
CC
≤2ns V
CC
/2 30pF 500 Ω
3.3V±0.3V 3V ≤2.5ns 1.5V 50pF 500 Ω
5V±0.5V V
CC
≤2.5ns V
CC
/2 50pF 500 Ω
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Figure 2. Load Circuit and Voltage Waveforms
Notes: A . Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10 MHz
C. Inputs are measured separately one transition per measurement
D. t
PLH
and t
PHL
are the same as t
PD
