Diodes 74LVC1G10 - Manual (Page 6)

74LVC1G10
SINGLE 3 INPUT POSITIVE NAND GATE
74LVC1G10
Document number: DS35121 Rev. 3 - 2
6 of 13
www.diodes.com
October 2011
© Diodes Incorporated
NEW PROD
UC
T
Switching Characteristics
T
A
= -40 °C to 85°C, CL = 15pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V Unit
Min Max Min Max Min Max Min Max
t
pd
Any Y 1.0 14.8 0.7 5.5 0.7 3.8 0.7 2.7 ns
T
A
= -40 °C to 85°C, CL = 30 or 50pF (see Figure 2)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V Unit
Min Max Min Max Min Max Min Max
t
pd
Any Y 1.0 18.0 0.7 6.5 0.7 5 0.7 3.6 ns
T
A
= -40 °C to 125°C, CL = 15 pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V Unit
Min Max Min Max Min Max Min Max
t
pd
Any Y 1.0 17.7 0.7 6.6 0.7 4.6 0.7 3.3 ns
T
A
= -40 °C to 125°C , CL = 30 or 50pF (see Figure 2)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V Unit
Min Max Min Max Min Max Min Max
t
pd
Any Y 1.0 21.6 0.7 7.8 0.7 6.0 0.7 4.3 ns
Operating Characteristics
T
A
= 25 ºC
Parameter
Test
Conditions
V
CC
= 1.8V V
CC
= 2.5V V
CC
= 3.3V V
CC
= 5V
Unit
Typ. Typ. Typ. Typ.
C
pd
Power dissipation
capacitance
f = 10 MHz 17 18 19 22 pF
