AH5792
SINGLE PHASE HALL EFFECT LATCH SMART
FAN MOTOR CONTROLLER
AH5792
Document number: DS314641 Rev. 6 - 2
5 of 10
www.diodes.com
July 2010
© Diodes Incorporated
Magnetic Characteristics (T
A
= 25
°C, Vdd = 1.8V~5.0V, Note 6)
(1mT = 10 G)
Symbol Parameter Min Typ. Max Unit
B
op
Operate Point 10 30 50 G
Brp Release Point -50 -30 -10 G
B
hy
Hysteresis - 60 - G
Notes: 6. The magnetic characteristics may vary with supply voltage, operating temperature and after soldering.
Operating Characteristics
OFF
OP
RP
ON
Ou
tp
u
t V
o
lt
ag
e
in
V
o
lts
OFF
RP
OP
ON
Out
p
ut
Vol
ta
g
e
i
n
Vol
ts
Bop Brp 0 Bop Brp 0
Magnetic Flux Density in Gauss Magnetic Flux Density in Gauss
V
OL
V
OL
V
OH
V
OH
O2 O1
Marking side
S
(SOT553)
N
Marking side
S
(SOT89-5L)
N
