AH5792
SINGLE PHASE HALL EFFECT LATCH SMART
FAN MOTOR CONTROLLER
AH5792
Document number: DS314641 Rev. 6 - 2
4 of 10
www.diodes.com
July 2010
© Diodes Incorporated
Absolute Maximum Ratings (T
A
= 25
°C, unless otherwise noted)
Symbol Characteristics Values Unit
Vdd Supply voltage 6 V
I
O(PEAK)
Maximum Output Current (Peak)
SOT553 400 mA
SOT89-5L 500 mA
P
D
Power Dissipation
SOT553 230 mW
SOT89-5L 800 mW
T
ST
Storage Temperature Range -65 ~ 150
o
C
Recommended Operating Conditions (T
A
= 25
°C)
Symbol Parameter Conditions Rating Unit
Vdd Supply Voltage Operating 1.8 to 5.0 V
T
A
Operating Temperature Range Operating -40 to +100
°C
Electrical Characteristics (T
A
= 25
°C, Vdd = 5.0V)
Symbol Characteristic Conditions Min Typ. Max Unit
Idd Supply Current No Load - 3.5 5 mA
V
OH
Output Voltage High
I
OUT
= 200mA
(For SOT553)
4.4 - - V
I
OUT
= 300mA
(For SOT89-5L)
V
OL
Output Voltage Low
I
OUT
= 200mA
(For SOT553)
- - 0.6 V
I
OUT
= 300mA
(For SOT89-5L)
I
OUT
Output Current R
L
=30 Ω - 148 - mA
I
Leak
FG Output Leakage Current - - 5 μA
I
FG
FG Output Current V
FGOL
= 0.4V 5 - - mA
V
FGOL
FG Output Voltage Low I
FG
= 5mA - - 0.4 V
T
ON
On Time - 215 - ms
R
DR
Duty Ratio T
OFF
/ T
ON
- 10 -
