4/6 CHANNEL CHARGE PUMP CURRENT SINK FOR LED DRIVER AP3606/AP3607
Jan. 2013 Rev. 1. 5 BCD Semiconductor Manufacturing Limited
4
Ordering Information
AP36XX -
Circuit Type G1: Green
Package
Temperature
Range
Part Number Marking ID
Packing
Type
QFN-3×3-16 -40 to 85 °C
AP3606FNTR-G1 B1B
Tape & Reel
AP3607FNTR-G1 B1C
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Input Voltage V
IN
-0.3 to 6 V
VOUT Pin Voltage (VOUT1 & VOUT2) V
OUT
-6 to 0.3 V
EN Pin Voltage V
EN
-0.3 to 6 V
C1+, C2+ Pin Voltage V
C+
-0.3 to 6 V
C1-, C2- Pin Voltage V
C-
-6 to 0.3 V
D1, D2, D3, D4 Pin Voltage AP3606
V
D
V
OUT
to V
IN
V
D1, D2, D3, D4, D5, D6 Pin Voltage AP3607
Thermal Resistance
(Junction to Ambient, No Heat Sink, Free Air)
θ
JA
60 ºC/W
Operating Junction Temperature T
J
150 ºC
Storage Temperature T
STG
-65 to 150 ºC
Lead Temperature (Soldering, 10sec) T
LEAD
260 ºC
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
TR: Tape and Reel
06: AP3606
07: AP3607
Package
FN: QFN-3Ч3-16
