Absolute Maximum Ratings
(Note 4)
Symbol
Parameter
Rating
Unit
V
IN
Input Voltage
18
V
T
J
Operating Junction Temperature
+150
°C
T
STG
Storage Temperature Range
-65 to +150
°C
T
LEAD
Lead Temperature (Soldering, 10sec)
+260
°C
θ
JA
Thermal Resistance (Junction to Ambient)
100
°C/W
—
ESD (Human Body Model)
2000
V
Note 4
: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
IN
Input Voltage
—
12
V
T
J
Operating Junction Temperature
0
+125
°C
