Typical Applications Circuit
AZ2085
ADJ/GND
V
OUT
= V
REF
* (1+R2/R1 ) + I
ADJ
* R2
R2
R1
V
IN
V
OUT
C
IN
=10 µF C
OUT
=22 µF
INPUT OUTPUT
3 2
1
Pin Descriptions
Pin Number Pin Name Function
1 ADJ/GND Adjust pin/Ground
2 OUTPUT Output voltage
3 INPUT Input voltage
