AP7365
600mA, LOW QUIESCENT CURRENT, FAST TRANSIENT
LOW DROPOUT LINEAR REGULATOR
AP7365
Document number: DS32260 Rev. 3 - 2
6 of 19
www.diodes.com
May 2012
© Diodes Incorporated
NEW PROD
UC
T
Typical Performance Characteristics
Load Transient Response
Time (100 μs/div)
Load Transient Response
Time (100 μs/div)
Load Transient Response
Time (100 μs/div)
Load Transient Response
Time (100 μs/div)
V
OUT
= 1.8V (200mV/div) V
OUT
= 1.8V (200mV/div)
V
IN
= V
EN
= 2.8V
C
IN
= C
OUT
= 1 μF
Tr = Tf = 1 μs
V
IN
= V
EN
= 2.8V
C
IN
= C
OUT
= 1 μF
Tr = Tf = 1 μs
I
OUT
= 10mA to 300mA (500mA/div)
I
OUT
= 10mA to 600mA (500mA/div)
V
OUT
= 3.3V (200mV/div)
V
IN
= V
EN
= 4.3V
C
IN
= C
OUT
= 1 μF
Tr = Tf = 1 μs
I
OUT
= 10mA to 300mA (500mA/div)
V
OUT
= 3.3V (200mV/div)
V
IN
= V
EN
= 4.3V
C
IN
= C
OUT
= 1 μF
Tr = Tf = 1 μs
I
OUT
= 10mA to 600mA (500mA/div)
