AP7340
Electrical Characteristics
(V
EN
= V
IN
= V
OUT
+1.0V, C
IN
= C
OUT
0.47µF, I
OUT
= 1.0mA @T
A
= +25°C, unless otherwise specified.)
Parameter Conditions
Min
Typ
Max
Units
Input Voltage
T
A
= -40°C to +85°C
1.7
5.25 V
Output Voltage Accuracy (Note 11)
V
IN
= (V
OUT
–
Nom
+1.0V) to
5.25V, I
OUT
= 1mA to 150mA
T
A
= +25°C
-1
1
%
T
A
= -40°C to +85°C
-1.5
+1.5
Line Regulation (dV
OUT
/dV
IN
/V
OUT
) V
IN
= (V
OUT – Nom
+1.0V) to 5.25V, I
OUT
= 1.0mA
0.02
0.1
%/V
Load Regulation
(dV
OUT
/V
OUT
/dI
OUT
)
V
IN
= V
OUT
-
Nom
+1.0V, I
OUT
= 1mA to 150mA
0.5
1.0
%/A
Quiescent Current
(Note 6)
I
OUT
= 0mA
35
50
uA
I
OUT
= 150mA
60
100
I
STANDBY
V
EN
= 0V (Disabled)
0.01
1.0
uA
Output Current
150
mA
Fold-back Short Current (Note 7)
V
OUT
short to ground
55
mA
PSRR (Note 8)
V
IN
= [V
OUT
+1V] VDC + 0.2Vp-pAC,
V
OUT
≥1.8V,
I
OUT
= 30mA
f = 1kHz
75
dB
Output Noise Voltage (Note 8)
(Note 9)
BW = 10Hz to 100kHz, I
OUT
= 30mA
60
µVrms
Dropout Voltage
(Note 5)
I
OUT
= 150mA
1.1V ≤ V
OUT
< 1.5V
0.50
0.62
V
1.5V ≤ V
OUT
< 1.7V
0.38
0.47
1.7V ≤ V
OUT
< 2.0V
0.34
0.42
2.0V ≤ V
OUT
< 2.5V
0.28
0.36
2.5V ≤ V
OUT
< 2.8V
0.22
0.30
2.8V ≤ V
OUT
≤ 3.6V
0.21
0.27
Output Voltage Temperature
Coefficient
I
OUT
= 30mA, T
A
= -40°C to +85°C
±30
ppm/C
EN Input Low Voltage
0
0.5
V
EN Input High Voltage
1.3
5.25
V
EN Input Leakage
V
EN
= 0, V
IN
= 5.0V or V
EN
= 5.0V, V
IN
= 0V
-1.0 +1.0
µA
On Resistance of N-channel for
auto-discharge (Note 10)
V
IN
= 4.0V V
EN
= 0V (Disabled)
30
Ω
Notes:
5. Dropout voltage is the voltage difference between the input and the output at which the output voltage drops 2% below its nominal value.
6. Quiescent current is defined here is the difference in current between the input and the output.
7. Short circuit current is measured with V
OUT
pulled to GND.
8. This specification is guaranteed by design.
9. To make sure lowest environment noise minimizes the influence on noise measurement.
10. AP7340 has 2 options for output, Built-in discharge and non-discharge
11. Potential multiple grades based on following output voltage accuracy.
