AP7362

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

(1) U-DFN2030-8

(2) SO-8EP

Dimensions

Value (in mm)

C

0.500

G

0.250

X

0.350

X1

1.500

X2

1.850

Y

0.600

Y1

1.600

Y2

3.300

Dimensions

Value

(in mm)

C

1.270

X

0.802

X1

3.502

X2

4.612

Y

1.505

Y1

2.613

Y2

6.500

X 2

Y 2

Y

X

Y 1

G

X 1

P i n 1

C

C

Y1

X1

X

Y

Y2

X2
