AP7115
150mA LOW DROPOUT LINEAR REGULATOR WITH
SHUTDOWN
AP7115 Rev. 10
2 of 11
MAY 2009
©
Diodes Incorporated
Ordering Information
AP7115 - XX XX G - 7
W : SOT25
Output voltage
Package
7 : Tape & Reel
Packing
Green
G : Green
10 : 1.0V
12 : 1.2V
15 : 1.5V
18 : 1.8V
25 : 2.5V
28 : 2.8V
29 : 2.85V
33 : 3.3V
30 : 3.0V
35 : 3.5V
SE : SOT353
Device
Package
Code
Packaging
(Note 2)
7” Tape and Reel
Quantity
Part Number Suffix
AP7115-XXWG-7
W
SOT25
3000/Tape & Reel
-7
AP7115-XXSEG-7 SE SOT353 3000/Tape
&
Reel
-7
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Pin Assignments
SOT25 / SOT353
IN
EN
BP
OUT
( Top View )
5
4
3
2
1
GND
Pin Descriptions
Pin Name
Pin NO.
Description
IN
1
Voltage Input
GND
2
Ground
EN
3
Chip Enable Control
BP
4
Band-Gap Bypass
OUT
5
Voltage Output
