AP1117/AP1117I
Document number: DS31009 Rev. 23 - 2
9 of 13
June 2013
© Diodes Incorporated
AP1117/AP1117I
Marking Information
(cont.)
(4) TO263
1117-VV
X : Internal code
YY : Year : 01~09
( Top View )
YY WW X X
WW : Week : 01~52
, 52 represents
Logo
G : Green
Part Number
VV: 15 for 1.5V
18 for 1.8V
25 for 2.5V
33 for 3.3V
50 for 5.0V
Blank for ADJ
52 and 53 week
L : Lead Free
(5) TO220-3
( Top View )
17 - VV
Logo
YY WW X X
Part Number
1117 for ADJ
17-VV : 15 for 1.5V
18 for 1.8V
25 for 2.5V
33 for 3.3V
50 for 5.0V
X : Internal code
WW : Week : 01~52
, 52 represents
YY : Year : 01~09
52 and 53 week
G : Green
L : Lead Free
Package Outline Dimensions
(All dimensions in mm.)
(1) Package Type: SOT223
SOT223
Dim Min Max Typ
A 1.55
1.65
1.60
A1 0.010
0.15 0.05
b1 2.90 3.10 3.00
b2 0.60 0.80 0.70
C 0.20
0.30
0.25
D 6.45
6.55
6.50
E 3.45
3.55
3.50
E1 6.90 7.10 7.00
e — —
4.60
e1 — — 2.30
L 0.85
1.05
0.95
Q 0.84
0.94
0.89
All Dimensions in mm
A1
A
