AP1117/AP1117I
Package Outline Dimensions
(cont.)
(All dimensions in mm.)
(2) Package
Type:
TO252
(3) Package
Type:
SOT89
(4) Package Type: TO263
TO252
Dim
Min Max Typ
A
2.19 2.39 2.29
A1
0.00 0.13 0.08
A2
0.97 1.17 1.07
b
0.64 0.88 0.783
b2
0.76 1.14 0.95
b3
5.21 5.46 5.33
c2
0.45 0.58 0.531
D
6.00 6.20 6.10
D1
5.21
e
2.286
E
6.45 6.70 6.58
E1
4.32
H
9.40 10.41 9.91
L
1.40 1.78 1.59
L3
0.88 1.27 1.08
L4
0.64 1.02 0.83
a
0° 10°
All Dimensions in mm
SOT89
Dim Min Max
A 1.40 1.60
B 0.44 0.62
B1 0.35 0.54
C 0.35 0.44
D 4.40 4.60
D1
1.62 1.83
E 2.29 2.60
e 1.50
Typ
H 3.94 4.25
H1 2.63 2.93
L 0.89 1.20
All Dimensions in mm
TO263
Dim Min Max
A
4.07 4.82
A1
0.00 0.25
b
0.51 0.99
b2
1.15 1.77
c
0.356 0.73
c2
1.143 1.65
D
8.39 9.65
D1
6.55
E
9.66 10.66
E1
6.23
e
2.54 Typ
H
14.61 15.87
L
1.78 2.79
L1
1.67
L2
1.77
a
0° 8°
All Dimensions in mm
b3
E
2X b2
D
L4
A
c2
e
A1
L
L3
3X b
a
H
A2
E1
E
H
D1
B1
B
e
C
L
A
D
8° (4X)
H
1
R0
.2
00
E
D
b2
b
e
c2
A
H
See Detail B
7°±1°
c
E1
D1
A1
Gauge Plane
L
L3
a
Detail B
Seating
Plane
L2
L1
1
2
K
