AP1115
Document number: DS31025 Rev. 11 - 2
6 of 8
August 2012
© Diodes Incorporated
AP1115
Ordering Information
Device Package
Code
Packaging
(Note 8)
13” Tape and Reel (Note 9)
Quantity
Part Number Suffix
AP1115XYXXL-13
Y
SOT89-3
2500/Tape & Reel
-13
AP1115XYXXG-13
Y
SOT89-3
2500/Tape & Reel
-13
AP1115XYXXL-13R
Y
SOT89-3
4000/Tape & Reel
-13R
AP1115XYXXG-13R
Y
SOT89-3
4000/Tape & Reel
-13R
Notes:
8. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
9. Find Surface Mount (SMD) Packaging and Reel and Carrier Tape specification in document AP02007.pdf
Marking Information
SOT89-3
1
3
2
X X
Y W
XX : Identification code
( Top View )
X
Y : Year : 0~9
W : Week : A~Z : 1~26 week;
X : Internal code
A~Z : Green
a~z : 27~52 week;
z represents 52 and 53 week
a~z : Lead Free
Output Version
Identification Code
AP1115A
AP1115B
ADJ
JO JU
1.5V
JP JV
1.8V
JQ JW
2.5V
JR JX
2.8V
JC JD
3.0V
JM JN
3.3V
JS JY
3.5V
JK JL
5.0V
JT JZ
Pb
Lead-Free
Pb
Lead-Free
