AP2186/ AP2196
Typical Performance Characteristics
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
Figure 1 Voltage Waveforms: AP2186 (left), AP2196 (right)
All Enable Plots are for AP2196 Active High
Channel 1 Turn-On Delay and Rise Time
400µs/div
Channel 1 Turn-Off Delay and Fall Time
400µs/div
Channel 2 Turn-On Delay and Rise Time
400µs/div
Channel 2 Turn-Off Delay and Fall Time
400µs/div
Vout 1
2V/div
Ven 1
5V/div
CL=1µF
TA= +25°C
RL=5Ω
Vout 1
2V/div
Ven 1
5V/div
CL=1µF
TA= +25°C
RL=5Ω
Vout 2
2V/div
Ven 2
5V/div
CL=1µF
TA= +25°C
RL=5Ω
Vout 2
2V/div
Ven 2
5V/div
CL=1µF
TA= +25°C
RL=5Ω
CL=1µF
TA= +25°C
RL=5Ω
