AL5801
Document number: DS35555 Rev. 3 - 2
6 of 11
www.diodes.com
July 2012
© Diodes Incorporated
AL5801
Typical Performance Characteristics
(cont.)
100
200
300
400
500
600
700
800
-50 0 50 100 150
JUNCTION TEMPERATURE ( C) °
Figure 11 V vs. Junction Temperature
REXT
V (
m
V
)
R
EXT
I = 0.1mA
V
bias
bias
= 5V
0 0
50
100
150
200
250
300
350
400
1 10 100
V (V)
OUT
Figure 12 Output Current vs. V
OUT
I (
m
A
)
OU
T
I = 0.1mA
T = 85°C
bias
A
50mm x 50mm
(2oz. FR4)
25mm x 25mm
(2oz. FR4)
15mm x 15mm
(2oz. FR4)
