Data Sheet
50V N-Channel MOSFET AF15N50
Aug. 2013 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
8
Mechanical Dimensions
PDFN-5×6-8 Unit: mm(inch)
1.20±0.10
4.700(0.185)
5.100(0.201)
1.000(0.039)
1.200(0.047)
5.600(0.220)
6.000(0.236)
0.100(0.004)
MAX
E
0.900(0.035)
1.100(0.043)
0.510(0.020)
0.710(0.028)
0.510(0.020)
0.710(0.028)
1.170(0.046)
1.370(0.054)
3.820(0.150)
4.020(0.158)
0.510(0.020)
MIN
0.330(0.013)
0.510(0.020)
0.210(0.008)
0.340(0.013)
8
12
0.060(0.002)
0.200(0.008)
Symbol
min(mm) max(mm) min(inch) max(inch)
Option 1
Option 2 5.150(BSC)
5.100
0.203(BSC)
0.201
DEPTH 0.05
+0
-0.05
3.180(0.125)
3.540(0.139)
D
3.700(0.146)
4.100(0.161)
3.280(0.129)
3.680(0.145)
1.000(0.039)
1.400(0.055)
D
min(mm) max(mm) min(inch) max(inch)
5.900
6.150(BSC)
6.100 0.232
0.242(BSC)
0.240
E
Option 1
Pin 1 Mark
Option 1
Option 2
-- --
