Page 3
Data Sheet
50V N-Channel MOSFET AF15N50
Aug. 2013 Rev. 1. 0
BCD Semiconductor Manufacturing Limited
3
Ordering Information
AF15N50
-
Circuit Type G1: Green
Package
DNP:
PDFN-5×6-8
TR: Tape & Reel
Package Part
Number
Marking ID
Packing Type
PDFN-5×6-8
AF15N50DNPTR-G1
15N50DNP-G1
Tape & Reel
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 1)
T
C
=25°C, unless otherwise specified.
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Parameter
Symbol Value
Unit
Drain to Source Voltage
V
DS
50
V
Continuous Drain Current
I
D
T
C
=25ºC 15
A
T
C
=100ºC 15
Pulsed Drain Current
I
DM
60
A
Gate to Source Voltage
V
GS
±12
V
Power Dissipation
P
D
31
W
Operating Temperature Range
T
OP
-55
to
150
ºC
Storage Temperature Range
T
STG
-55
to
150
ºC
