Electrical Characteristics
(@T
A
= +25°C, V
DD
= 3V, unless otherwise specified.)
T
A
= +25°C, V
IN
= 3.3V, V
OUT
= V
FB
, I
OUT
= 5mA, unless otherwise specified.) (Note 4)
Symbol Parameter
Conditions
Min Typ Max Units
V
FB
Feedback voltage
ZXRE160A
0.597 0.6 0.603
V
ZXRE160
0.594 0.6 0.606
T
A
= 0°C to +85°C
ZXRE160A 0.595
0.605
ZXRE160 0.592
0.608
T
A
= -40°C to +85°C
ZXRE160A 0.594
0.606
ZXRE160 0.591
0.609
T
A
= -40°C to +125°C
ZXRE160A 0.593
0.607
ZXRE160 0.590
0.610
FB
LOAD
Feedback pin load
regulation
I
OUT
= 1 to 15mA
3.8
6
mV
T
A
= -40 to +125°C
10
FB
LINE
Feedback pin line
regulation
V
IN
= 2V to 18V
0.3 1
mV
V
IN
= 2.2V to 18V
T
A
= -40 to +125°C
1.5
FB
OVR
Output voltage
regulation
V
OUT
= 0.2V to 18V,
I
OUT
= 1mA
(Ref. Figure 1)
1
mV
T
A
= -40 to +125°C
1.5
I
FB
FB input bias current
V
IN
= 18V
-45
nA
T
A
= -40 to +125°C
-200 0
V
FB
= 0.7V
-50 50
I
IN
Input current
V
IN
= 2V to 18V
I
OUT
= 0.3mA
0.35
0.7
mA
V
IN
= 2.2V to 18V
T
A
= -40 to +125°C
1
V
IN
= 2V to 18V
I
OUT
= 10mA
0.48
1
mA
V
IN
= 2.2V to 18V
T
A
= -40 to +125°C
1.5
V
IN
= 18V, I
OUT
= 0.3mA
V
FB
= 0.7V
3
I
OUT(LK)
OUT leakage current
V
IN
= 18V,
V
OUT
= 18V,
V
FB
=0V
0.1
µA
T
A
= +125°C
1
Z
OUT
Dynamic Output
Impedance
I
OUT
= 1 to 15mA
f < 1kHz
0.25
0.4
Ω
T
A
= -40 to +125°C
0.6
PSRR
Power supply rejection
ratio
F = 300kHz
V
AC
= 0.3V
PP
>45 dB
BW
Amplifier Unity Gain
Frequency
Ref: Figure 2
600 kHz
G
Amplifier
Transconductance
5000 mA/V
Note:
4. Production testing of the device is performed at +25
°C. Functional operation of the device and parameters specified over the operating temperature
range are guaranteed by design, characterization and process control.
