ZXRE160
Document number: DS35688 Rev. 2 - 2
4 of 15
June 2012
© Diodes Incorporated
ZXRE160
NEW PROD
UC
T
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Voltages to GND, @T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Rating
Unit
V
IN
IN Voltage relative to GND
20
V
V
OUT
OUT Voltage relative to GND
20
V
V
FB
FB Voltage relative to GND
20
V
P
GND
PGND Voltage relative to GND
-0.3 to +0.3
V
I
OUT
OUT Pin Current
20
mA
T
J
Operating Junction Temperature
-40 to 150
°C
T
ST
Storage Temperature
55 to 150
°C
These are stress ratings only. Operation outside the absolute maximum ratings may cause device failure.
Operation at the absolute maximum rating for extended periods may reduce device reliability.
Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events.
Suitable ESD precautions should be taken when handling and transporting these devices.
Package Thermal Data
Package
θ
JA
P
DIS
T
A
= 25°C, T
J
= 150°C
SC70/SOT353 400°C/W
310mW
TSOT25 250°C/W 500mW
X2-DFN1520-6 TBD
TBD
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Min
Max
Units
V
IN
IN Voltage Range (0 to +125°C)
2
18
V
V
IN
IN Voltage Range (-40°C to 0°C)
2.2
18
V
OUT
OUT Voltage Range
0.2
18
I
OUT
OUT Pin Current
0.3
15
mA
T
A
Operating Ambient Temperature
Range
-40 +125 °C
