AVSL 130.030-130.033 AMD SERIES User Manual

Page 2

AMD Series User Manual

INTRODUCTION:

Thank you for choosing Mercury AMD series distribution amplifier. It is designed to amplify weak
FM/DAB/TV aerial from aerial and distribute to multiple outputs, ideal for domestic or commercial use
to distribute FM/DAB/DTV(DVB-T, ATSC, ISDB, T-DMB)/Sat signal to different room/area.

PRODUCT FEATURES:

Separate dedicated inputs for VHF and UHF signal.

Built in low noise high gain amplifier to boost weak signals from aerial.

Built in mixer to give wideband VHF and UHF output.

Integrated LTE signal filter avoids interference and channel loss from 4G mobile signal.

Full gain output to for a long cable run.

DC pass allows the control of satellite via Magic Eye remote extender (124.157UK)

Built in surge and short circuit protection, and maximum output limiter prevents overload.

SPECIFICATION:

AMD02

AMD04

AMD06

AMD08

Item ref

130.030UK

130.031UK

130.032UK

130.033UK

No of inputs

No of outputs

2+Full

4+Full

6+Full

8+Full

Frequency
response

47-300MHz,
470-862MHz

Max output level

94dBµV

90dBµV

87dBµV

Gain per split

12dB

8dB

Gain on Full

20dB

Noise

<4dB

Isolation loss

22dB

Dimensions

134.5 x 70 x
44.4mm

179.5 x 70 x
44.4mm

224.5 x 70
x 44.4mm

269.5 x 70
x 44.4mm

Weight

270g

350g

420g

500g

INSTALLATION:

Before installing please ensure all devices to be connecting to the amplifier are switched off and
disconnected to the mains. The unit is designed to be connected via “F” connectors for secure
connections, for coax connector (RF/IEC 169-2/Belling-Lee), a coax to “F” connector adaptor will be
required. At the back of the case there are two mount holes which allow unit to be wall mounted.

AMD distribution amplifiers are designed to amplify weak signals and distribute them to different
locations. For installations that are close to TV transmitters, some user may experience blocking or a
frozen picture. An attenuator may be required to reduce the input signal to the amplifier.
