AMPLUG02
PLUG-IN 2-WAY DISTRIBUTION
AMPLIFIER

Item ref: 130.036UK

User Manual



















SPECIFICATION:

Power:

230Vac, 50Hz

Frequency range:

47 – 862MHz

Gain per split:

10-20dB

Noise :

<4dB

Impedance:

75Ω

Max output level:

90dBuV

Dimensions & weight:

135 x 75 x 42mm, 240g

INTRODUCTION:


Thank you for choosing this Mercury plug-in distribution amplifier. It is designed to amplify
weak FM/DAB/TV signals from the aerial and distribute them to 2 outputs. Simply connect the
aerial and TV, plug into the mains socket and it is ready to use.

CAUTION

Please read through this manual carefully before use. This product is strictly

for indoor use only, please install this product in dry and cool environment

and keep out of the reach of children and pets.
