APPENDIx
A. SPARK LIST OF SPARE PARTS
The parts authorized in this list of spare parts are required for operator maintenance. This list includes
parts that must be removed in order to replace authorized parts.
ITEM NO. Column indicates the number used to identify items in Figure A-1.
PART NO. Column indicates the primary number used by the manufacturer to identify an item; this
number controls the design and characteristics of the item by means of its engineering, specifications,
standards, and inspection requirements.
9 7
10
FIGURE A-1. SPARK SPARE PARTS
4
5
6
2
11
3 1
8
14
TABLE A-1. SPARK LIST OF SPARE PARTS
ITEM NO. DESCRIPTION PART NO.
1. Battery Cap SPARKBC
2. CR123A Lithium Battery CR123A
3. Battery Cap Retainer SPARKBCR
4. Lens Cap SPARKLC
5. Objective Lens Assembly SPARKOLA
6. Eyepiece Assembly SPARKEPA
7. Eyecup Assembly SPARKECA
8. Function Switch SPARKFS
9. Rail SPARKPR
10. Operation and Maintenance Manual SPARKOUMM
11. Soft Carry Case SPARKSCC
12. Shipping/Storage Case SPARKSSC
