26
NOTE:
The IR illuminator is designed to provide additional illumination (when needed) while viewing
scenes or targets from a short distance (up to 3m).
To activate the IR illuminator, turn the monocular on. Flip the function switch (A) CW from ON to the IR
position. A red indicator (Fig. 3-15, B) lights when the IR illuminator is turned on.
FIGURE 3-15. IR ILLUMINATOR OPERATIONS
A B
3.3.3 SPARK SHUT-DOWN
1. Turn the function switch to OFF. The green glow of the viewing area will fade to black.
2. Secure the lens cap over the objective lens.
3. If necessary, remove the unit from the rail (from the scope lens). Remove the unit by following the
mounting instructions in reverse.
4. Unscrew the battery cap and take out the battery. Replace the battery cap. Do not store the unit with
the battery still in it.
5. Store the unit and all accessories in the case.
3.4 STORAGE
3.4.1 PREPARATIONS FOR STORAGE
Prepare the Spark for storage as follows:
1. Verify that the Spark and all accessories are clean and dry before returning them to the storage
case.
2. Secure the cap over the objective lens.
3. Remove the battery.
4. Place the Spark and accessories in the appropriate locations in the case, and close the cover.
