14
2.3 STANDARD COMPONENTS
The standard components of the Spark are shown in Figure 2-2 and listed in Table 2-6.
The ITEM NO. column indicates the number used to identify items in Figure 2-2.
1
2
3
4
5
6
FIGURE 2-2. SPARK STANDARD COMPONENTS
TABLE 2-6. SPARK STANDARD COMPONENTS
ITEM NO. DESCRIPTION qUANTITY
1 Night Vision Monocular 1
2 Lens Cap 1
3 Eye-cup 1
4 Battery 123A Lithium 1
5 Operation and Maintenance Manual 1
6 Carrying Case 1
1) Armasight Spark Night Vision Monocular
Monocular night vision device with unity magnification.
2) Lens Cap
A cap used to protect the lens and to be used when testing the unit in daylight.
3) Eye-cup
A rubber cup used to protect the eyepiece as well as provide comfort for the operator.
4) Battery 123A Lithium
A single, 123A lithium battery used to power the unit.
5) Operation and Maintenance Manual
Provides safety information, equipment description, mounting procedures, operating instructions,
and preventive maintenance checks and service (including a List of Spare Parts).
6) Carrying Case
A protective case used for storing and carrying of the Spark and its accessories.
2.4 OPTIONAL EqUIPMENT
Optional items are shown and listed in Table 2-7.
The PART NO. column indicates the primary number used by the manufacturer to identify an item.
