15
TABLE 2-6. NYX-14 STANDARD COMPONENTS
ITEM NO. DESCRIPTION qUANTITY
1 Night Vision Monocular 1
2 Lens Cap 1
3 Eye-cup 1
4 Battery Adapter 1
5 Battery 123A Lithium 1
6 Operation and Maintenance Manual 1
7 Carrying Case 1
1) Armasight NYX-14 Night Vision Monocular
Monocular night vision device with unity magnification.
2) Lens Cap
A cap used to protect the lens and to be used when testing the unit in daylight.
3) Eye-cup
A rubber cup used to protect the eyepiece as well as provide comfort for the operator.
4) Battery Adapter
Allows of use of a single 3V CR123 or 1.5V AA batteries.
5) Battery 123A Lithium
A single, 123A lithium battery used to power the unit.
6) Operation and Maintenance Manual
Provides safety information, equipment description, mounting procedures, operating instructions,
and preventive maintenance checks and service (including a List of Spare Parts and an Intensifier Tube
Replacement Manual).
7) Carrying Case
A protective case used for storing and carrying of the NYX-14 and its accessories.
2.4 OPTIONAL EqUIPMENT
Optional items are shown and listed in Table 2-7.
The PART NO. column indicates the primary number used by the manufacturer to identify an item.
TABLE 2-7. NYX-14 OPTIONAL EqUIPMENT
IMAGE DESCRIPTION PART NO.
3x A-Focal Lens #22
Quickly converts the NYX-14 into a long-range night vision
device. Ideal for long range observation. ANAF3X0002
5x A-Focal Lens
Quickly converts the NYX-14 into a long-range night vision
device. Ideal for long range observation. ANAF5X0002
