13
EqUIPMENT ITEM DIMENSIONS, MM (L X W X H)/(DIA X L) WEIGHT, G
Camera Adapter* Dia 60х22 52
Dovetail to Weaver Transfer Piece* 38х21х7.5 8
Transfer Adapter to Standard US Mil Headset* 49х46х64 50
3X Afocal Lens* Dia 64х77 188
5X Afocal Lens* Dia 78х90 344
5X Lens* Dia 80х141 500
8X Lens* Dia 96х211 730
* Optional
** For Nyx-14 MG version.
TABLE 2-3. ELECTRICAL DATA
ITEM DATA
Battery* One AA (1.5 V) or 123A (3 V)
Consumption Current**:
- at 1.5 VDC
- at 3.0 VDC
75 mA
38 mA
Continuous Operation** at 20 o C (68 o F):
- AA Alkaline Battery
- 123A Lithium Battery
30 (IT Gen. 2+) / 25 (IT Gen. 3)
60 (IT Gen. 2+) / 50 (IT Gen. 3)
* Any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.7V can be used.
** With IR illuminator off.
TABLE 2-4. OPTICAL DATA
ITEM DATA
Magnification:
— with 1X Lens
— with 5X Lens*
— with 8X Lens*
— with 3X Afocal Lens* and F27 Lens
— with 5X Afocal Lens* and F27 Lens
(1±0.05) X
(5±0.2) X
(8±0.5) X
(3±0.15) X
(5±0.2) X
1X Lens:
— Focal Length
— Lens F/number
27 mm
1:1.2
Focus Range:
— with 1X Lens
— with 5X Lens*
— with 8X Lens*
— with 3X Afocal Lens*
— with 5X Afocal Lens* 0.25 m to infinity
10 m to infinity
15 m to infinity
5 m to infinity
10 m to infinity
TABLE 2-2. CONTINUED
