After 3 seconds the system defaults to the STANDBY mode and the LCD displays the following:
* MAIN MENU
Sample
Span
Zero
Alarm
System
Standby
Standby
Auto Range
85⁰F 100Kpa
12/31/07 12:00:00
Menu Format
Menu displayed – displayed on the top line in the upper left corner of the display.
Menu options available - displayed in the upper left corner of the display under the current menu on the top line.
Menu option selected - indicated by the cursor (*) positioned to the left of the menu option selected.
System mode - indicated at the top center of the display.
Range mode and current auto or fixed manual range - displayed on the first line at the bottom of the display.
Temperature inside the analyzer and ambient pressure - displayed on the second line at the bottom of the display.
Note: In the event power to the analyzer is interrupted, the system defaults to the “Standby” mode when power is
restored. To resume sampling, advance the cursor (*) to “Sample” mode, press ENTER to select and select the
range mode as described below.
Menu Navigation
The four (4) pushbuttons located on the front of the analyzer control the system’s micro-processor:
1. Green - ENTER (select)
2. Yellow UP ARROW – advance cursor up
3. Yellow DOWN ARROW – advance cursor down
4. Red – ESC (menu)
Select menu option by advancing cursor (*) by repeatedly pressing the yellow UP/DOWN ARROW keys.
Accept the menu option selected with cursor (*) by pressing the green ENTER key.
Abort the menu option selected with cursor (*) and return to the previous menu by pressing the red ESC key.
Note: If a selection is not made within 30 seconds, the system returns to the MAIN MENU.
