2-22 ASUS P8Z68-M PRO
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high definition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
Allows you to select the digital audio output type. Configuartion options: [SPIDF] [HDMI]
ASM1061 Storage Controller [AHCI Mode]
Allows you to enable or disable the ASM1061 Storage Controller. Configuartion options:
[AHCI Mode] [IDE Mode] [Disabled]
ASM1061 Storage OPROM [Enabled]
This item appears only when the ASM1061 Storage Controller item is set to [AHCI Mode] or
[IDE Mode].
[Enabled] Enables the ASM1061 Storage OPROM.
[Disabled] Disables the ASM1061 Storage OPROM.
Realtek LAN Controller [Enabled]
[Enabled] Enables the Realtek LAN controller.
[Disabled] Disables the controller.
Realtek PXE OPROM [Disabled]
This item appears only when you set the Realtek LAN Controller item to [Enabled] and
allows you to enable or disable the Rom Help of the Realtek LAN controller.
Configuration options: [Enabled] [Disabled]
Asmedia USB 3.0 Controller [Enabled]
[Enabled] Enables the USB 3.0 controller .
[Disabled] Disables the controller.
Asmedia USB 3.0 Battery Charging Support [Disabled]
This item appears only when the Asmedia USB 3.0 Controller item is set to [Enabled].
[Enabled] Enables the Asmedia USB 3.0 battery charging function.
[Disabled] Disables this function
Serial Port Configuration
The sub-items in this menu allow you to set the serial port configuration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Configuration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select the Serial Port base address. Configuration options: [IO=3F8h;
IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
Parallel Port Configuration
The sub-items in this menu allow you to set the parallel port configuration.
Parallel Port [Enabled]
Allows you to enable or disable the parallel port (LPT).
