2-16 ASUS P8Z68-M PRO
Long duration power limit [Auto]
Use the <+> and <-> keys to adjust the value.
Long duration maintained [Auto]
Use the <+> and <-> keys to adjust the value.
Short duration power limit [Auto]
Use the <+> and <-> keys to adjust the value.
Additional Turbo Voltage [Auto]
Use the <+> and <-> keys to adjust the value.
Primary Plane Current Limit [Auto]
Use the <+> and <-> keys to adjust the value.
Secondary Plane Current Limit [Auto]
Use the <+> and <-> keys to adjust the value.
Some of the following items are adjusted by typing the desired values using the numeric
keypad and press . You can also use the <+> and <-> keys to adjust the value. To
restore the default setting, type [auto] using the keyboard and press .
2.4.10 CPU Offset Mode Sign [+]
This item appears only when the EPU Power Saving Mode item is set to [Disabled].
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Voltage [Auto]
This item appears only when the EPU Power Saving Mode item is set to [Disabled] and
allows you to set the Offset voltage. The values range from -0.315V to +0.635V with a
0.005V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
2.4.11 iGPU Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
iGPU Voltage [Auto]
Allows you to set the Offset voltage. The values range from -0.315V to +0.635V with a
0.005V interval.
2.4.12 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.185V to 2.135V with a 0.005V
interval.
According to Intel CPU specification, DIMMs with voltage requirement over 1.65V may
damage the CPU permanently. We recommend you install the DIMMs with the voltage
requirement below 1.65V.
