2.5.2 2.5.2 2.5.2 2.5.2 2.5.2 Hardware monitor Hardware monitor Hardware monitor Hardware monitor Hardware monitor
This menu shows the hardware monitor settings auto-detected by the
BIOS.
Select Menu
Item Specific Help
Press [Enter] to enable
or disable.
Hardware Monitor
Q-Fan Controller [Enabled]
Vcore Voltage 1.50V
3.3V Voltage 3.31V
5V Voltage 4.94V
12V Voltage 11.26V
CPU Temperature 48ºC
M/B Temperature 38ºC
CPU FAN Speed 4962 RPM
CHA1 FAN Speed 0 RPM
CPU Target Temperature [66ºC]
Q-Fan Controller [Enabled] Q-Fan Controller [Enabled] Q-Fan Controller [Enabled] Q-Fan Controller [Enabled] Q-Fan Controller [Enabled]
Allows you to enable or disable the Q-Fan controller.
Configuration options: [Disabled] [Enabled]
VCORE Voltage, +12V Voltage, 3.3V Voltage, 5VCC VCORE Voltage, +12V Voltage, 3.3V Voltage, 5VCC VCORE Voltage, +12V Voltage, 3.3V Voltage, 5VCC VCORE Voltage, +12V Voltage, 3.3V Voltage, 5VCC VCORE Voltage, +12V Voltage, 3.3V Voltage, 5VCC
Voltage
Voltage Voltage Voltage Voltage
The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators. These items are not
user-configurable.
CPU Temperature, M/B Temperature CPU Temperature, M/B Temperature CPU Temperature, M/B Temperature CPU Temperature, M/B Temperature CPU Temperature, M/B Temperature
The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. These items are not user-configurable.
CPU Fan Speed/CHA1 Fan Speed CPU Fan Speed/CHA1 Fan Speed CPU Fan Speed/CHA1 Fan Speed CPU Fan Speed/CHA1 Fan Speed CPU Fan Speed/CHA1 Fan Speed
The onboard hardware monitor automatically detects and displays the
Chassis, CPU, and Chip fan speeds in rotations per minute (RPM). If the fan
is not connected to the motherboard, the field shows 0. These items are
not user-configurable.
