Asus A8N-SLI User Manual

Page 16

1 - 6

C h a p t e r 1 : H a r d w a r e i n f o r m a t i o n

I n t e r n a l c o n n e c t o r s

P a g e

1. Floppy disk drive connector (34-1 pin FLOPPY1)

1-20

2. Serial port connector (10-1 pin COM1)

1-20

3. IDE connectors (40-1 pin PRI_IDE, SEC_IDE)

1-21

4. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4)

1-22

5. CPU fan connector (3-pin CPU_FAN)

1-23

6. Chassis fan connectors (3-pin CHA1_FAN, CHA2_FAN)

1-23

7. Chipset fan connector (3-pin CHIP_FAN)

1-23

8. Power fan connector (3-pin PWR_FAN)

1-23

9. USB connectors (10-1 pin USB78, USB56, USB910)

1-24

10. IEEE 1394a connector (10-1 pin IE_1394_2)

1-24

11. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V1, 4-pin EZ_PLUG)

1-25

12. Internal audio connectors (4-pin AUX, 4-pin CD)

1-26

13. Front panel audio connector (10-1 pin FP_AUDIO)

1-26

14. Chassis intrusion connector (4-1 pin CHASSIS)

1-27

15. System panel connector (10-1 pin FRONTPANEL)

1-28
