2 - 1 4 2 - 1 4 2 - 1 4 2 - 1 4 2 - 1 4 C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p C h a p t e r 2 : B I O S s e t u p
First SATA Master
x Auto Acoustic Management Disabled
Extended IDE Drive [Auto]
Access Mode [Auto]
Capacity 0 MB
Cylinder 0
Head 0
Precomp 0
Landing Zone 0
Sector 0
2.3.6 2.3.6 2.3.6 2.3.6 2.3.6 First, Second, Third, and Fourth SATA Master First, Second, Third, and Fourth SATA Master First, Second, Third, and Fourth SATA Master First, Second, Third, and Fourth SATA Master First, Second, Third, and Fourth SATA Master
The BIOS automatically detects the values opposite the dimmed items
(Capacity, Cylinder, Head, Precomp, Landing Zone and Sector). These
values are not user-configurable. These items show 0 if no SATA device is
installed in the system.
Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto] Extended IDE Drive [Auto]
Select [Auto] to automatically detect a SATA hard disk drive. If automatic
detection is successful, Setup automatically fills in the correct values for
the remaining fields on this sub-menu. Configuration options: [None]
[Auto]
Access Mode [Auto] Access Mode [Auto] Access Mode [Auto] Access Mode [Auto] Access Mode [Auto]
Allows the user to select the sector addressing mode. Refer to the
previous page for detailed descriptions of the different modes.
Configuration options: [Large] [Auto]
Before attempting to configure a hard disk drive, make sure you have
the correct configuration information supplied by the drive
manufacturer. Incorrect settings may cause the system to fail to
recognize the installed hard disk.
Select Menu
Item Specific Help
Sets the type of fixed
disk connected to the
system.
