DRAM Configuration

DRAM Configuration

DRAM Configuration

DRAM Configuration

DRAM Configuration

The items in this sub-menu show the DRAM-related information that the
BIOS auto-detects.

DRAM Configuration

Timing Mode

[Auto]

x

Memclock index value (Mhz)

200Mhz

x

CAS# Latency (Tcl)

2.5
x

Min RAS# active time (Tras)

8T

x

RAS# to CAS# delay (Trcd)

4T

x

Row precharge time (Trp)

2T
x

1/T/2T Memory Timing

2T

Bottom of 32-bit [31:24] IO

[E0]

DRAM Over 4G Remapping

[Disabled]

MTRR mapping mode

[Continuous]

Select Menu

Item Specific Help

to select DRAM
configuration. [Auto] is
recommended. [Manual]
allows you to set each
configuration on your
own.

2.4.2

2.4.2

2.4.2

2.4.2

2.4.2

Chipset configuration

Chipset configuration

Chipset configuration

Chipset configuration

Chipset configuration

The items in this menu show the chipset configuration settings. Select an
item then press to display a pop-up menu with the configuration
options.

Chipset

DRAM Configuration

[Press Enter]

Errata 94 Enhanced

[Enabled]

Select Menu

Item Specific Help

DRAM timing and
control.
