Asus Adaptec 2025 ZCR User Manual
Page 154
G-3
Controller Illustrations
Adaptec SCSI RAID 2130SLP Component Layout
Adaptec SCSI RAID 2200S Component Layout
Adaptec
Battery connector
External VHDCI
SCSI connector
Low-profile bracket
Internal high-density
SCSI connector
PCI-X connector
Adaptec
Battery connector
PCI connector
Internal high-density
SCSI connectors
External VHDCI
SCSI connectors
Low-profile bracket
