2-2

Chapter 2: Hardware information

7. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports are

available for connecting USB 2.0/1.1 devices.

8. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are

available for connecting USB 2.0/1.1 devices.

9. Coaxial S/PDIF Out port. This port connects an external audio output device

via a coaxial S/PDIF cable.

10. Serial port. This port connects a modem, or other devices that conform with

serial specification.

11. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.

Audio 2, 4, or 6-channel configuration

Light Blue

Line In

Line In

Line In

Lime

Line Out

Front Speaker Out Front Speaker Out

Pink

Mic In

Mic In

Mic In

Port

2-channel

-channel

-channel

2.7.2.

Internal.connectors

1.. Floppy.disk.drive.connector.(34-1.pin.FLOPPY)

This connector is for the provided floppy disk drive (FDD) signal cable. Insert

one end of the cable to this connector, then connect the other end to the

signal connector at the back of the floppy disk drive.

Pin 5 on the connector is removed to prevent incorrect cable connection when

using a FDD cable with a covered Pin 5.

P5LD2-X/1333

P5LD2-X/1333.

Floppy.Disk.Drive.Connector

NOTE: Orient the red markings on

the floppy ribbon cable to PIN 1.

PIN 1

FLOPPY
