A S U S P 5 A D 2 P r e m i u m

4 - 2 1

The following items also appear when the A I O v e r c l o c k i n g

A I O v e r c l o c k i n g

A I O v e r c l o c k i n g item is set

to [AI NOS].

Memory Voltage [Auto]

Allows you to select the DDR2 reference voltage.
Configuration options: [1.80V] [1.90V] [2.00V] [2.10V] [Auto]

Refer to the DDR2 documentation before adjusting the memory voltage.
Setting a very high memory voltage may damage the memory module(s)!

Chipset Core Voltage [Auto]

Allows you to select the chipset core voltage.
Configuration options: [1.50V] [1.60V] [Auto]

Setting a high chipset core voltage may damage the chipset!

CPU VCore Voltage [Auto]

Allows you to select the CPU VCore voltage. Configuration options: [Auto]
[1.7000V] [1.6875V] [1.6750V] [1.6625V] [1.6500V] [1.6375V]
[1.6250V] [1.6125V] [1.6000V] [1.5875V] [1.5750V] [1.5625V]
[1.5500V] [1.5375V] [1.5250V] [1.5125V] [1.5000V] [1.4875V]
[1.4750V] [1.4625V] [1.4500V] [1.4375V] [1.4250V] [1.4125V]
[1.4000V] [1.3875V]

Refer to the CPU documentation before setting the CPU Vcore voltage.
Setting a high Vcore voltage may damage the CPU!

FSB Termination Voltage [Auto]

Allows you to select the front side bus termination voltage.
Configuration options: [1.20V] [1.40V] [Auto]

The following item appears only when the A I O v e r c l o c k i n g

A I O v e r c l o c k i n g

A I O v e r c l o c k i n g item is set

to [Overclock Profile].

Overclock Options [Overclock 5%]

Allows you to overclock the CPU speed through the available preset values.
Configuration options: [Overclock 5%]

[FSB888/DDR2-667]

[Overclock 10%]

[FSB900/DDR2-600]

[Overclock 15%]

[FSB950/DDR2-633]

[Overclock 20%]

[FSB1000/DDR2-667]

[Overclock 30%]

[FSB1066/DDR2-533]
[FSB1066/DDR2-710]
