2 - 2 8

C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n

1 0 .

1 0 . IEEE 1394b

IEEE 1394b

IEEE 1394b p o r t

p o r t

p o r t connectors (10-1 pin IE1394B_1,

connectors (10-1 pin IE1394B_1,

I E 1 3 9 4 B _ 2

I E 1 3 9 4 B _ 2 [ p u r p l e ]

[ p u r p l e ]

[ p u r p l e ])))))

These connectors are for IEEE 1394b ports. Connect the IEEE 1394b
module cable (purple) to this connector, then install the module to a
slot opening at the back of the system chassis. Refer to the IEEE
1394b driver information on page 5-9 for details.

Never connect a U S B c a b l e

U S B c a b l e

U S B c a b l e to the IEEE 1394b connectors.

Doing so will damage the motherboard!

1 1 .

1 1 . GAME/MIDI port connector (16-1 pin GAME1)

G A M E / M I D I p o r t c o n n e c t o r ( 1 6 - 1 p i n G A M E 1 )

G A M E / M I D I p o r t c o n n e c t o r ( 1 6 - 1 p i n G A M E 1 )
This connector is for a GAME/MIDI port. Connect the USB/GAME
module cable to this connector, then install the module to a slot
opening at the back of the system chassis. The GAME/MIDI port
connects a joystick or game pad for playing games, and MIDI devices
for playing or editing audio files.

You can connect an optional IEEE 1394a module cable to these
connectors.

P5AD2 PREMIUM

P5AD2 PREMIUM IEEE 1394 connectors

IE1394B_2

A1-

GND

TPB1-

+12V

GND

A1+

GND

TPB1+

+12V

IE1394B_1

A2-

GND

TPB2-

+12V

GND

A2+

GND

TPB2+

+12V

P5AD2 PREMIUM

P5AD2 PREMIUM GAME connector

GAME1

+5V

J2B1

J2CX

MIDI_OUT

J2CY

J2B2

MIDI_IN

J1B1

J1CX

GND

J1CY

J1B2

+5V
