4 - 1 2 4 - 1 2 4 - 1 2 4 - 1 2 4 - 1 2 C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p C h a p t e r 4 : B I O S s e t u p
4.2.2 4.2.2 4.2.2 4.2.2 4.2.2 Menu bar Menu bar Menu bar Menu bar Menu bar
The menu bar on top of the screen has the following main items:
M a i n M a i n M a i n M a i n M a i n For changing the basic system configuration
A d v a n c e d A d v a n c e d A d v a n c e d A d v a n c e d A d v a n c e d For changing the advanced system settings
P o w e r P o w e r P o w e r P o w e r P o w e r For changing the advanced power management (APM)
configuration
B o o t B o o t B o o t B o o t B o o t For changing the system boot configuration
E x i t E x i t E x i t E x i t E x i t For selecting the exit options and loading default
settings
To select an item on the menu bar, press the right or left arrow key on the
keyboard until the desired item is highlighted.
4.2.3 4.2.3 4.2.3 4.2.3 4.2.3 Navigation keys Navigation keys Navigation keys Navigation keys Navigation keys
At the bottom right corner of a menu screen are the navigation keys for
that particular menu. Use the navigation keys to select items in the menu
and change the settings.
4.2.1 4.2.1 4.2.1 4.2.1 4.2.1 BIOS menu screen BIOS menu screen BIOS menu screen BIOS menu screen BIOS menu screen
Some of the navigation keys differ from one screen to another.
System Time [11:10:19]
System Date [Thu 03/27/2003]
Legacy Diskette A [1.44M, 3.5 in]
Language [English]
Primary IDE Master :[ST320413A]
Primary IDE Slave :[ASUS CD-S340]
Secondary IDE Master :[Not Detected]
Secondary IDE Slave :[Not Detected]
Third IDE Master :[Not Detected]
Fourth IDE Master :[Not Detected]
IDE Configuration
System Information
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
N a v i g a t i o n k e y s N a v i g a t i o n k e y s N a v i g a t i o n k e y s N a v i g a t i o n k e y s N a v i g a t i o n k e y s
G e n e r a l h e l p G e n e r a l h e l p G e n e r a l h e l p G e n e r a l h e l p G e n e r a l h e l p M e n u b a r M e n u b a r M e n u b a r M e n u b a r M e n u b a r
S u b - m e n u i t e m s S u b - m e n u i t e m s S u b - m e n u i t e m s S u b - m e n u i t e m s S u b - m e n u i t e m s
C o n f i g u r a t i o n f i e l d s C o n f i g u r a t i o n f i e l d s C o n f i g u r a t i o n f i e l d s C o n f i g u r a t i o n f i e l d s C o n f i g u r a t i o n f i e l d s M e n u i t e m s M e n u i t e m s M e n u i t e m s M e n u i t e m s M e n u i t e m s
