ASUS P8Z77-V PRO/ THUNDERBOLT
3-23
Chapter 3
Main
Ai Tweaker
Advanced
Monitor
Boot
Tool
Exit
Enabled/Disabled the High Precision
Event Timer.
Back
Advanced\
PCH Configuration >
EFI BIOS Utility - Advanced Mode
PCH Configuration
High Precision Timer
Enabled
> Intel(R) Rapid Start Technology
> Intel(R) Smart Connect Technology
High Precision Timer [Enabled]
Allows you to enable or disable the High Precision Event Timer.
Configuration options: [Enabled] [Disabled]
Intel Rapid Start Technology [Disabled]
Allows you to enable or disable Intel Rapid Start Technology.
Configuration options: [Enabled] [Disabled]
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S4 mode.
Configuration options: [Enabled] [Disabled
Entry After [Immediately]
Allows you to set the wake-up time.
Configuration options: [Immediately] [1 minute] [2 minutes] [5 minutes] [10 minutes]
[15 minutes] [30 minutes] [1 hour] [2 hours]
Active Page Threshold Support [Enabled]
The system automatically set itself to sleep when the partition size is not enough for
Rapid Start Technology to work.
Configuration options: [Enabled] [Disabled]
Active Memory Threshold [0]
Key in the value for the additional partition size for Rapid Start Technology to work.
Ensure that the caching partition size is larger than the total memory size.
Intel Smart Connect Technology [Disabled]
Allow you to enable or disable Intel Smart Connect Technology.
Configuration options: [Enabled] [Disabled]
3.5.2
PCH Configuration
