ASUS P8Z77-V PRO/ THUNDERBOLT 3-31
Chapter 3
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Wi-Fi Controller [Enabled]
[Enabled] The Wi-Fi function of ASUS Wi-Fi GO! card is enabled.
[Disabled] The Wi-Fi function of ASUS Wi-Fi GO! card is disabled.
Thunderbolt bandwidth [Auto]
[Auto] Thunderbolt runs at X2 mode for system resource optimization.
(PCIeX1_2 will be disabled.)
[X4] Thunderbolt runs at X4 mode for high performance support.
(SATA6G_E12, USB3_E12, PCIeX1_2 will be disabled.)
[X2] Thunderbolt runs at X2 mode for more available PCIeX1 slots.
(SATA6G_E12 will be disabled)
ASM1061 Storage Controller [Enabled]
Allows you to select the ASM1061 storage controller operating mode.
[Disabled]
Disables the controller.
[Enabled] Enables the controller.
ASM1061 Storage OPROM [Enabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the OptionRom of the ASM1061storage controller.
Configuration options: [Enabled] [Disabled]
ASmedia USB 3.0 Controller (USB3_E12) [Enabled]
[Enabled] Enables the USB 3.0 controller.
[Disabled] Disables the controller.
ASmedia USB 3.0 Battery Charging Support [Disabled]
[Enabled] Enables Asmedia USB 3.0 fast battery charging support for USB 3.0
devices complying with the BC 1.1 regulation.
[Disabled] Disables battery charging support.
Intel LAN Controller [Enabled]
[Enabled] Enables the Intel LAN controller.
[Disabled] Disables the controller.
Intel PXE OPROM [Disabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the PXE OptionRom of the Intel LAN controller.
Configuration options: [Enabled] [Disabled]
