2. FEATURES
2. FEA
TURES
Motherboard Parts
1 SEC CPU Socket
2 Intel 440BX AGPset
3 2 DIMM Sockets
4 Primary, Secondary IDE Connectors
5 Function DIP Switches
6 ATX Power Connector
7 Programmable Flash EEPROM
8 Serial COM2 Header
9 Multi I/O Chip
10 Floppy Disk Drive Connector
11 Intel PIIX4E PCIset
12 TI 1394 Link Layer Chip
13 ASUS ASIC with hardware monitor
14 Accelerated Graphics Port
15 Wake-On-Ring Connector
16 Wake-On-LAN Connector
17 3 PCI Slots
18 Aureal 3D PCI Audio (optional)
19 AC’97 V2.1 Audio CODEC (for audio model only)
20 TI 1394 Physical Layer Chip
21 T: Joystick/MIDI Connector
B: Line Out, Line In, Microphone In Connectors
(for audio model only)
22 IEEE-1394 Headers (channels 2 & 3)
23 IEEE-1394 Connector (channel 1)
24 Parallel Port Connector
25 Serial Port Connector
26 2 USB Connectors
27 T: PS/2 Mouse Connector
B: PS/2 Keyboard Connector
2.3 ASUS P3B-1394 Part Descriptions
