ASUS P5NT WS 4-21
Select Menu
Item Specific Help
Set C55 PCIE Overclock
System Clocks
NB PCIEX16 Frequency [Auto]
SB PCIEX16 Frequency [Auto]
SPP<->MCP Ref Clock, MHz [Auto]
Phoenix-AwardBIOS CMOS Setup Utility
Advanced
System Clocks
NB PCIEX16 Frequency/SB PCIEX16 Frequency [Auto]
Allows you to set the NB/SB PCIEX16 overclocking frequency. Use the <+> and <->
keys to adjust the frequency. The values range from 100 to 200.
SPP<->MCP Ref Clock, MHz [Auto]
Configuration options: [Auto] [200.0 MHz] [200.5 MHz] [201.0 MHz]...[500.0 MHz]
F1:Help ↑↓: Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit
Select Menu
Item Specific Help
System clock mode
[Optimal]
Set FSB and memory speed
automatically.
[Linked]
Enter FSB Speed manually.
Memory Speed changes
proportionally.
FSB - Memory Clock Mode [Auto]
x FSB - Memory Ratio Auto
x FSB (QDR), MHz Auto
Actual FSB (QDR), MHz 800.0
x MEM (DDR), MHz Linked
Actual MEM (DDR), MHz 667
Phoenix-Award BIOS CMOS Setup Utility
Extreme Tweaker
FSB & Memory Config
FSB & Memory Config
FSB - Memory Clock Mode [Auto]
Allows you to set the memory clock mode.
Configuration options: [Auto] [Linked] [Unlinked]
The following items become user-configurable when you set the FSB-Memory
Clock Mode item to [Linked].
FSB - Memory Ratio [Auto]
Configuration options: [Auto] [1:1] [5:4] [3:2] [Sync Mode]
FSB (QDR), MHz [800]
Use the numeric keypad to enter a new value or use the <+> and <-> keys to adjust
the frequency. The values range from 533 to 3000.
The following items become user-configurable when you set the FSB-Memory
Clock Mode item to [Unlinked].
