ASUS KCMR-D12 4-31
The following items appear only when the Resume On RTC Alarm item is set
to [Enabled].
RTC Alarm Date [15]
To set the alarm date, highlight this item and press the <+> or <-> key to make the
selection.
System Time [12:30:30]
Use the , or key to select a field. Use the <+> or <->
key to configure alarm time.
4.6.6 Hardware Monitor
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU1 Temperature [ 35ºC/ 94ºF]
CPU2 Temperature [ N/A Re]
TR1 Temperature [ N/A ]
TR2 Temperature [ N/A ]
CPU Fan1 Speed [ N/A ]
CPU Fan2 Speed [ N/A ]
Front Fan1 Speed [ N/A ]
Front Fan2 Speed [ N/A ]
Front Fan3 Speed [ N/A ]
Front Fan4 Speed [ N/A ]
Rear Fan1 Speed [ N/A ]
Rear Fan2 Speed [ N/A ]
Fan Speed Control [Whisper Mode]
VCORE1 [ 1.052 V]
VCORE2 [ 1.052 V]
P1DDR3 Voltage [ 1.180 V]
P2DDR3 Voltage [ 1.180 V]
P1_+1.2V Voltage [ 1.204 V]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU1 Temperature
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
P2_+1.2V Voltage [ 1.204 V]
P1_VDDNB Voltage [ 1.090 V]
+1.8V Voltage [ 1.826 V]
+1.2V Voltage [ 1.170 V]
+1.1V Voltage [ 1.084 V]
+12V Voltage [11.952 V]
+5V Voltage [ 5.043 V]
+3.3V Voltage [ 3.228 V]
+5VSB Voltage [ 5.075 V]
+3.3VSB Voltage [ 3.240 V]
VBAT Voltage [ 3.000 V]
Scroll down for more items.
CPU1/CPU2/TR1/TR2 Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the motherboard
component and CPU temperatures. Select [Ignored] if you do not wish to display
the detected temperatures.
