4-18 Chapter 4: BIOS setup
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
NorthBridge Configuration
SouthBridge Configuration
SR5670 Configuration
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
4.4.2 Chipset Configuration
The Chipset configuration menu allows you to change advanced chipset settings.
Select an item then press to display the sub-menu.
Options for NB
NorthBridge Configuration
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
CPU Bridge Chipset Configuration
CPU REVISION :B0
Current CSI Frequency :6.400GT
Current Memory Frequency :1066 Mhz
CSI Links Speed [Full-Speed]
CSI Frequency [Auto]
Memory Frequency [Auto]
Memory Mode [Independent]
Demand Scrubbing [Disabled]
Patrol Scrubbing [Disabled]
Throttling - Closed Loop [Disabled]
Throttling - Open Loop [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
To transition the CSI
links to full-speed
or leave them in
slow-mode.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
NorthBridge Chipset Configuration
Memory Configuration
ECC Configuration
DRAM Timing Configuration
Memory CLK :667 MHz, N/A
CAS Latency(Tcl) :8 CLK , N/A
RAS/CAS Delay(Trcd) :8 CLK , N/A
Row Precharge Time(Trp) :8 CLK , N/A
Min Active RAS(Tras) :24 CLK , N/A
RAS/RAS Delay(Trrd) :4 CLK , N/A
Row Cycle(Trc) :32 CLK , N/A
Read to Precharge(Trtp) :5 CLK , N/A
Write Recover Time(Twr) :10 CLK , N/A
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
