xi
KCMR-D12 specifications summary
Model Name KCMR-D12
Processor Support / System Bus 2 * socket C32 (LGA 1207)
4/6 Core AMD Opteron™ 4100 series
HyperTransport™ Technology 3.0
6.4 GT/s per link (dual link)
Core Logic AMD SR5670 / AMD SP5100
Form Factor 12” x 13”
ASUS Features Fan Speed
Control
V
Rack Ready
(Rack and
Pedestal dual
use)
V
ASWM 2.0 V
Memory Total Slots 12 (2-channel per CPU)
Capacity Maximum up to 128GB (RDIMM)
Maximum up to 32GB (UDIMM)
Memory Type DDR3 1066/1333 UDIMM with ECC/ non ECC
DDR3 667/800/1066/1333 RDIMM
Memory Size 1GB, 2GB, 4GB, 8GB* (RDIMM)
1GB, 2GB, 4GB (UDIMM)
Expansion Slots
(follow SSI Loacation #)
Total PCI/PCI-X/
PCI-E Slots
5
Slot Loacation 1 1 * PCI-E x8 (Gen2 X4/X0 Link, share with
additional slot 1)
Slot Loacation 3 1 * PCI-E x8 (Gen2 X8 Link)
Slot Loacation 4 1 * PCI-E x8 (Gen2 X8/X0 Link, share with slot 6)
Slot Loacation 6 1 * PCI-E x16 (Gen2 X16/8 Link.auto switch with
slot4)
Slot Loacation 7 1 * PCI 32bit/33 MHz
Additional Slot 1 1* PIKE Slot for Stroage expansion
Storage SATA Controller AMD SP5100:
6 SATA2 300MB/s ports
SAS Controller Optional:
ASUS PIKE 1064E 4-port SAS RAID card
ASUS PIKE 1068E 8-port SAS RAID card
ASUS PIKE 1078 8-port SAS HW RAID card
ASUS PIKE 6480 8-port SAS RAID card
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID
card
Networking LAN 2 * Intel 82574L
Graphic VGA Aspeed AST2050 8MB
