4-22 Chapter 4: BIOS setup
SouthBridge Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
SouthBridge Chipset Configuration
SP5100 CIMx Version : 5.6.0
SB Azalia Audio Configuration
SB Debug Configuration
OHCI HC (Bus 0 Dev 18 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 18 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 18 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 19 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 20 Fn 5) [Enabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Options for SB HD
Azalia
SB Azalia Audio Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
Onchip HD Azalia Configuration
Advanced
HD Audio Azalia Device [Auto]
HD Onboard PIN Config [Enabled]
Azalia Front Panel [Auto]
SDIN0 Pin Config [Azalia]
SDIN1 Pin Config [Azalia]
SDIN2 Pin Config [Azalia]
SDIN3 Pin Config [Azalia]
Azalia Snoop [Disabled]
Azalia Clock Gating [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Auto : When MIO is
installed then MIO
will be enabled.
HD Audio Azalia Device [Auto]
Allows you to enable or disable the HD Audio Azalia device.
Configuration options: [Auto] [Disabled] [Enabled]
HD Onboard PIN Config [Enabled]
Allows you to enable or disable the HD onboard PIN configuration.
Configuration options: [Disabled] [Enabled]
Azalia Front Panel [Auto]
Allows you to enable or disable the Azalia Front Panel.
Configuration options: [Auto] [Disabled]
SDIN0/1/2/3 [Azalia]
Configuration options: [GPIO] [Azalia]
